Pick up the crowbar of research scientist Gordon Freeman, who finds himself on an alien-infested Earth being picked to the bone, its resources depleted, its populace dwindling. Freeman is thrust into the unenviable role of rescuing the world from the wrong he unleashed back at Black Mesa. And a lot of people, people he cares about, are counting on him.

Post tutorial Report content RSS feed Hammer Beginners Tutorial (With pictures!)

A beginners tutorial which covers learning the tools of the hammer editor, building a room, texturing the room, adding in a info_player_start, learning how to light our room properly, adding in a npc_zombie, adding a static prop, adding weapon, compiling map and finally testing your map.

Posted by BeginnersMod on Nov 15th, 2008
Basic Mapping/Technical.

My assumption in this tutorial is you have just opened the hammer editor for the first time and are trying to learn how to make yourself a fully functional room. Part 2 of this tutorial can be found here.

We will be:

  • Learning the tools of the hammer editor
  • Building a room
  • Texturing the room
  • Adding in a info_player_start
  • Learning how to light our room properly
  • Adding in a npc_zombie
  • Adding a static prop
  • Adding weapon
  • Compiling map
  • Testing map

Ok first I will go over the most commonly used tools:

The first tool on the bar is the selection tool. The hotkey for this tool is Shift+S. This tool allows you to select object such as brushes or props inside of your editor.

User Posted Image

The second tool on the bar is the magnify tool. The hotkey for this tool is Shift+G. This tool allows you to zoom in on the selected view port to where ever you clicked.

User Posted Image

The third tool is the Camera tool, this tool is very important if you want a 3D viewport. Select this tool, click and drag in your view port, and you will now have a camera you can navigate with. The hotkey is Shift+C

User Posted Image

The fourth tool is the Entity tool, this tool is one of the most important tools you will use, this tool allows you to add important things into your map such as lights, player starts, weapons and the list goes on.

User Posted Image

The fifth tool is the most important tool you will use. This tool is the Block tool. Select this tool to add walls/rooms to your level. Just click and drag in your viewport . The hotkey for this tool is Shift+B

User Posted Image

The sixth tool is the Toggle Texture Application tool. This tool allows you to add textures to individual walls within your map. This tool has many different features such as texture scaling, texture shifting, rotation, lightmap scale, and even the very handy displacement tool which I will get more into in later tutorials. The hotkey for this tool is Shift+A

User Posted Image

The seventh tool is the Apply Current Texture tool. This tool is a fast way to apply one texture to an entire brush or block within your map. If you click this tool it will apply a texture to the brush you have selected. There is no hotkey for this tool.

User Posted Image

The eighth tool is the Apply decals tool. This tool allows you to apply certain things like textures but not textures. These are called decals. The sort of things I am talking about is blood trails or spray paint to make your map feel realistic. The hotkey for this tool is Shift+D

User Posted Image

The ninth tool is the Apply Overlays tool, I will explain this tool in later tutorials. The hotkey for this tool is Shift+O

User Posted Image

The tenth tool is the Clipping tool. This tool is used for clipping parts of brushes off. This tool is used a lot for door ways/windows and also for rounding edges.

User Posted Image

Last but not least, the Vertex Manipulation tool, this tool is great for creating interesting architecture in your map. Just click this tool and drag the yellow corners to where ever you desire. The hotkey for this

User Posted Image

Ok now that you know about the important tools and hotkeys. We will start building our room.

User Posted Image

Above you will see 4 screens, those are called view ports. Each viewport is used for something different (Top, Side, Front, Bottom, 3D)

Select the Block tool User Posted Image and drag a box in your top right view port, this view port is called the "Top" view port

User Posted Image

I made my brush 256x256. You can make your brush what ever size you want to make it. But I am going to keep mine at 256x256.

User Posted Image

In the "Side" view port please make your height 128 units high. This is the standard height for Half life 2.

User Posted Image

Press the enter key on your keyboard when you are happy with the size of your brush and it will now create it.

Now take the Camera too User Posted Image and drag it in the top view port to make a camera. You should now see your brush in the top left view port. This view port is called the 3D view port or "Camera"

To navigate this view port press the "Z" key and use W,A,S,D keys to navigate it.

W- Forward
S- Backwards
A- Left
D- Right

It should now look like this:

User Posted Image

Ok so now you are probably wondering "Well, I got a box... but how is this a room?" Well we are going to change that right now.

Press CTRL+H to bring up the hollow tool. This tool will make your box hollow in the inside so that you can run inside and outside of it. Set your value to something around -4. Negative values make the walls push outwards there for not affecting the size of the inside of your room.

User Posted Image

(Sorry for the quality of this picture. I don't know what happened)

You now should have something like this on the inside.

Ok now it is time to put some textures in our room.

Select the Toggle Texture Application too User Posted Image and then click "Browse..."

User Posted Image

you will now get something like this come up:

User Posted Image

On the bottom where it says "Filter:"

Type in something like "Plaster" scroll through until you find a texture you like and want to use on your walls.

I used the texture called plaster/plasterwall005c (Feel free to copy and paste that into the filter and use same one.)

Ok now select the wall you would like to apply it to and click "Apply." To select multiple walls hold down control key (ctrl) and click all 4 walls.

Your room should now look like this:

User Posted Image

ok now it is time to do the floor. Follow the steps from before except type something different into the filter. I used the tile called brick/brickfloor001a. Your room should now look like this:

User Posted Image

Ok it is now time to change the ceiling. Again repeat the steps from above but this time change the search to something like concrete. I used concrete/concretefloor026a. Your room should now look something like this:

User Posted Image

Ok so there are 2 things you NEED to have in order to run a map:

  • Info-player_start
  • Light

So lets add them then. First click your Entity tool and on the right you will see a box which shows you what Entity you have selected and ready to go into your map.

User Posted Image

As you can see by default you start with the info_player_start entity selected. So now all you have to do is click on the ground in your room.

User Posted Image

Your room should now look like this.

We now need to add a light. So on your Entities box again click Objects and a drop down menu should appear. Press the "L" key on your key board and the first thing that should come up is light. Press enter and now you have your light selected. Again click anywhere on the floor and you will see a light bulb appear. This is actually what is going to light the room. In our other view ports move the light around until it is in the center of the room and closer to the ceiling.

User Posted Image

You should now have it looking like this. Ok so now we need to add a light prop so that it appears the light is coming from a source. Go to the entities box again. Open the drop down menu again and type in "prop_static" place this on the map and in the 3D view port and select the selection tool, double click on the static_prop box so that a window pops up.

User Posted Image

Click on "World Model" like in the picture above and then click "Browse..."

User Posted Image

this will pop up. It is called the "Model Browser"

here you can select any prop from HL2 and put it in your map. For now we are going to type "light" into the filter and select the model we want to use.

For this I chose "models/props_c17/light_domelight02_on.mdl"

Put this prop on the ceiling above your light model.

User Posted Image

Your room should now look like the picture above. If you need to change your grid size to place your prop in the right size use the "[ ]" keys.

Ok now we are going to add an npc_zombie.

Click the Entity tool and open the drop down list again. Type in npc_zombie and press enter. Click anywhere on the floor in the map and there's your zombie.

User Posted Image

Ok now we need to add a weapon to fight this zombie with. So repeat the same steps as above but instead type in "weapon_crowbar"

And click beside your info_player_start to put it down.

User Posted Image

Now we need to compile our map.

Click the "Run Map!" button on the top tool bar (or press hotkey F9)

User Posted Image

save your map to whatever you want to call it, I will save mine to mymap1

After you save it a window will pop up:

User Posted Image

keep everything the same and just click "OK"

your map will compile and when its done you can open halflife 2 press "~" to open your developers console if that dosnt work you must to to option and allow developers console,type in map and then type in your file name for example I would type in:

map mymap1

press enter and your map will load. ENJOY!

User Posted Image
User Posted Image

Thank you for reading this tutorial, I hope you learned a few things about mapping and the hammer editor. Read on for part 2. This tutorial was written by Intermission (Andy)

Post comment Comments
mjnowak Nov 15 2008 says:

Nice tut, but whats wrong with your color?

+2 votes     reply to comment
Sebultura Nov 15 2008 says:

Just my 2 cents: it's always more attractive to see the result in the end of a tutorial, so maybe, by just adding a screenshot of the room ingame would do it ?

Anyway, like other people making tutorials: thanks for the effort.

+2 votes     reply to comment
Silverfisk Nov 15 2008 says:

Pretty nice, I just have two complaints. There is no "standard height" for Half-Life 2, and you don't need lights to compile and run your map.

Other than that, great tutorial! :-)

+4 votes     reply to comment
StaindK Nov 18 2008 replied:

The 2nd part is right, but by 'standard height' I suspect he meant the standard TEXTURE height, for painting the walls and such...

+2 votes     reply to comment
Silverfisk Feb 16 2009 replied:

Yeah, it's the standard height for wall textures, but you can't really say it's just the standard height

+2 votes     reply to comment
BadgerDeluxe Nov 15 2008 says:

Agreed, its a very good tutorial, but would be a little better if you showed a screenshot of the end product.

+2 votes     reply to comment
BeginnersMod Author
BeginnersMod Nov 15 2008 says:

Hey guys,

thanks for all the comments. I hope this tutorial helped you in some way.

I posted the in-game pics on the bottom of the tutorial.

There will be more tutorials coming very shortly so if you like this one, keep your eyes open and you will see more :)


+2 votes   reply to comment
JohnnyMaverik Jul 3 2010 replied:

Thanks for this, I've never touched hammer before so I'll give you some feedback from a true (but very enthusiastic, don't judge me, I could be brilliant one day :( ) noob.

Maybe this will be the first step toward me starting work on the stellar mod I've been designing (on paper) for the past year now... LOL, well we can all dream can't we. God it's depressing not being talented :'(

+2 votes     reply to comment
Fddlrnthrf Nov 16 2008 says:

Very well written, my friend. I appreciate this tutorial very much.

Maybe I'll slate my mod for Source after all. UT3 frustrates me.

+2 votes     reply to comment
elcor Nov 16 2008 says:

thanks man is great!!

+2 votes     reply to comment
BeginnersMod Author
BeginnersMod Nov 16 2008 says:

Glad you 2 liked it..

writing an addition to this one as we speak

+2 votes   reply to comment
hushpuppy Nov 16 2008 says:

The images are VERY poor quality....colors are all messed up.

+2 votes     reply to comment
thenzkiwi Nov 18 2008 says:

How do you make ladders?

Ive lever had a clue how to do it.

+2 votes     reply to comment
BeginnersMod Author
BeginnersMod Nov 18 2008 replied:


put a ladder beside a wall and then put a func_useableladder 1 unit away from the ladder but infront of it. in one of the side view ports drap the circle in the middle func_useableladder until it is at the top of the ladder and then select the entity tool again and get a info_ladder_dismount put one on the bottom of the ladder and one on the top on the other floor. There we go a useable ladder


only thing I can think of is use your mouse wheel to scroll out as far as you can until you find your room again. If that dosnt work then im not sure

+2 votes   reply to comment
clonemann Nov 18 2008 says:

how do I get the camera in the top view because it dosen't show anything!

+2 votes     reply to comment
Xylemon Nov 18 2008 says:

I don't care that most of the images are poor quality it's the tut that matters and this tut is great!

+2 votes     reply to comment
Connall Nov 23 2008 says:

i am having a problem where the texture is see through it is just an outlined box

+2 votes     reply to comment
kathir Nov 24 2008 says:

the tutorial is very good . i expect tutorials for character design..

+2 votes     reply to comment
BeginnersMod Author
BeginnersMod Nov 29 2008 says:

you expect tutorials for character design?

well first of all, thats kind of rude, so you can go be rude somewhere else.. who are you to demand something?

second of all, character design and level design are two different things..

+2 votes   reply to comment
Guest Aug 14 2013 replied:

This comment is currently awaiting admin approval, join now to view.

Frozencloud Dec 9 2008 says:

Thanks for the tutorial! Really helped alot! :)!

But i have a problem with the Block tool.
When i press Enter. My box doesn't have any texture.
Just the outline of the box... Help :(

+2 votes     reply to comment
Fjahgo Jan 13 2009 says:

I dont think kathir from India meant to say "expect" :> and as others have pointed out, although you don't NEED light to run your map it's a good idea when you are creating a closed room which would otherwise be pitch black.

+2 votes     reply to comment
clonemann Mar 10 2009 says:

I was wondering if a had a block could a rotate it?

+2 votes     reply to comment
Inferno-998 Mar 29 2009 says:

This method does not work form me. When i click the room, it selects as one entitiy

+2 votes     reply to comment
Stevic Apr 14 2009 says:

Why thanks super 'BeginnersMod' person, I know that many who are entering the HL2 modding world for first time feel a lot safer knowing that a true super hero 'BeginnersMod' is watching over them!
Thanks! whoever you are!

+2 votes     reply to comment
KRiWOLF Jul 27 2009 says:

Hello, firstly thanks for going to the effort of explaining for beginners, like myself :] secondly, whats the difference between creating a single brush (box) and hollowing it (negatively) versus creating 6 gap-less brushes (boxes). Does the difference affect the lighting or textures or game-play or further modding in any way?

Thanks a ton. KRiWOLF

+2 votes     reply to comment
golf888 Sep 12 2009 says:

This's great. Thank you very much. I'm making my mod too.

+2 votes     reply to comment
AlekZanDer Sep 21 2009 says:

A little advise:Never start your map with a hollowed box.It's better you to make a room yourself rather than hollowing a box.Why?You will find out when you become real mappers.

+2 votes     reply to comment
ZaneLear Jan 5 2010 says:

I am following directions and on the texturing part it made my texture flip upside down and etc but I fixed it by hitting the fit button on the right hand side of the textures box if anyone has the same issue.

Also he ment Tile/Tilefloor010a the brick one is the default it comes in.

+2 votes     reply to comment
Johny11fingers Mar 11 2010 says:

Nice tutorial!

+2 votes     reply to comment
FishnChips Jun 3 2010 says:

im sorry but when i start a new file the view ports are black, i cant see anything i try to put on there

+2 votes     reply to comment
JK4ever Sep 13 2010 says:

Argh, thx! one great tutorial!

+2 votes     reply to comment
JK4ever Sep 13 2010 says:

but why cant i put an oil drum in? everytime i set it somewhere in the map it's disappears then i run it.

+2 votes     reply to comment
JK4ever Sep 14 2010 replied:

forget it, found out :) had to use physics instead of static :P

+2 votes     reply to comment
AmaroqDricaldari May 11 2011 says:

Can this guide tell me how to add to the Source Engine? One person added Python Support to the Source Engine and made it a public download, and the person working on Dual Reality, without a commercial license, added Soft Body physics and demonstrated it with the Jelly Cube. I asked this because I wanted to add PhysX to the Source Engine.

+2 votes     reply to comment
